Name: LED LAMP CP22SM
SKU: 8527
Availability: InStock

LED LAMP CP22SM
LED Lamp with socket, magnet mounting,motion sensor, 100-240 V 50 Hz

FEATURES	Unit	LEDLAMPCP22	LEDLAMPSP22
				Power supply	V \| Hz	230 \| 50/60	230 \| 50/60
Schuko socket	–	Yes 6A	No
Luminosity	Lm	900
Lamp type	–	LED
Power consumption	W	6
				Service life	hrs	30000
Switch	–	On/Off for the lamp only
Connection	–	3-pole terminal for 1.5 mm² wire
Casing	–	Aluminium profile and ABS, UL94 V0, light grey
Protection degree EN60529	–	IP20
Protection class	–	Class I, earthed
Operating temperature	°C(°F)	-20 / +50 (-4 / +122)
				Storage temperature	°C(°F)	-45 / +80 (-49 / +176)
Mounting	–	Clip on DIN rail, magnet or bracket, see ordering code below
Installation position	–	variable
Dimensions HxWxD	mm	95x43x277
Weight (with packaging)	kg	0.39 (0.47)
Package dimensions HxWxD	mm	105x58x310
Conformity/Certifications	–	CE

Data Sheet

Test / Quality Data

Drawing
