XNTN-9000-75-2GX8GT-M
XNTN-9000-75-2GX8GT-M - Image 2
, ,

XNTN-9000-75-2GX8GT-M

Compare

This is a gigabit managed industrial switch. It features 8 10/100/1000Base-T ports and 2 1000M
SFP fiber interfaces.
Designed to industrial-grade standards, this switch can withstand various harsh environments. Its
compact and portable design allows for easy installation in space-constrained control cabinets. Thanks to
its unique hardware and software capabilities, it supports flexible networking and is widely applicable in
industrial automation control, road traffic control automation, building automation systems, and data
center monitoring systems. The product is stable, reliable, and efficient, creating a rock-solid industrial
Internet of Things system for enterprises.
Product Features

₹14,500.00 ₹18,850.00

Inquire on WhatsApp
Compare
Add to quote

This is a gigabit managed industrial switch. It features 8 10/100/1000Base-T ports and 2 1000M
SFP fiber interfaces.
Designed to industrial-grade standards, this switch can withstand various harsh environments. Its
compact and portable design allows for easy installation in space-constrained control cabinets. Thanks to
its unique hardware and software capabilities, it supports flexible networking and is widely applicable in
industrial automation control, road traffic control automation, building automation systems, and data
center monitoring systems. The product is stable, reliable, and efficient, creating a rock-solid industrial
Internet of Things system for enterprises.
Product Features

Categories: , ,


Standards & Protocol 10Base-T, compliant with IEEE 802.3
100Base-TX, compliant with IEEE 802.3u
1000Base-T, compliant with IEEE 802.3ab
1000Base-X, compliant with IEEE 802.3z
Flow control, following IEEE 802.3x
Environmentally friendly, compliant with IEEE 802.3az
Interface information SFP: 8 1000Base-X（compatible with 100M)
Transmission rate: 1.25G
Multi-mode: 550m/2km; Single-mode: 2/20/40/60/80/100km
Multimode: 850nm/1310nm, single mode: 1310nm/1550nm/1490nm
RJ45 network port: 8 10/100/1000M Base-T ethernet ports (standard RJ45)
10/100/1000Mbps adaptive
10Base-T: ≤100m (CAT3,4,5 UTP)
100Base-TX: ≤100m (CAT3,4,5 UTP)
1000Base-T: ≤100m (CAT3,4,5 UTP)
Reset interface Reset button
Fluctuation switch 1 indicator light fluctuation switch (2nd gear: DATA, POE)
Mechanical properties Shell material: metal shell
Appearance dimensions (length*depth*height): 164mm×137mm×45mm
Installation method: DIN rail type
Heat dissipation method: natural cooling, no fan
Weight: <1.5KG
Environmental properties Working temperature: -40℃～+75℃
Storage temperature: -40℃～+85℃
Relative humidity: 5% ~ 95% (non-condensing)
Exchange properties Bandwidth: 32Gbps
Packet forwarding rate (whole machine) : 18Mpps
Exchange method: store-and-forward
MAC table : 10K
Case space : 4.1m
 Power supply Input voltage: DC 44V-58V
Power interface: 6-core Phoenix terminal
Power supply protection: positive and negative pole misconnection protection
Power consumption: < 10 W
Indicator Port indicator(fluctuation switch control):When Switch Point to Data : 10/100M Link/ACT yellow, 1000M Link/ACT green;
Power supply: Green
System: Green
Security properties Shell protection: IP40
Surge impact IEC61000-4-5 (optional):Signal end: common mode ±4KV, differential mode ±2KVPower supply end: common mode ±4KV, differential mode ±2KV
Anti-static interference IEC61000-4-2: contact discharge ±8KV, air discharge ±15KV
Pulse immunity IEC61000-4-4: signal terminal: ±2KV, power terminal: ±2KV
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
MTBF: 100000 hours
Warranty 3 years

Software features

Monitoring function Information such as device model, serial number, MAC, hardware version, software version, system time, running time, CPU utilization, memory utilization, etc. can be viewed
Support port statistics
   VLAN function Support management VLAN
Support management IP configuration
Support port VLAN
Supports VLANs for IP subnets
Support MAC VLAN
Support Voice VLAN
Support GVRP
Port function Support port configuration
Support port aggregation
Support port mirroring
Support port speed limit
Support port isolation
Support port energy saving
Scene function Support MAC configuration (static binding and dynamic binding)
Support DHCP Snooping
Support IGMP-Snooping, MLD Snooping
Support LLDP configuration
Support QOS configuration
Support Jumbo Frame
security function Support ARP configuration
Support storm control
Support ACL (based on IP, MAC, time)
Support attack prevention (DOS, Icmp-echo)
Support DHCP Snooping
Support 802.1X
Support Radius authentication
Ring network function Support STP
Support RSTP
Support MSTP
Support ERPS
Troubleshooting function Support loop protection
Support log management
Support Ping detection
Support traceroute
Support line detection
Device management function Support HTTP/HTTPS
Support TELNET
Support SNMP
Support RMON
Equipment maintenance function Support system time (local and NTP)
Support account management (hierarchical management of accounts and password protection)
Support configuration management (configuration import, export, restore factory settings)
Support system upgrade
Support device restart
